MPL120

PERFORMANCE

Nominal flow rating : on inlet port with compensator 150 l/min
                               on working ports with compensator 100 l/min
                               on working ports without compensator 130 l/min
Operating pressure (Max.) : 315 bar
Back pressure (Max.) : 25 bar (on outlet port T )
Oil leaks from A (B) to T : 16 c.c/min at 100 bar(1450 psi)
Fluid : best use mineral oil with viscosity ranging between 15 to 75 mm /s
Fluid temperature : Min. -20°C , Max 80°C ,with NBR (BUNA-N) gaskets
                             Min. -20°C ,Max 100°C ,with FPM (VITON) seals gaskets
